Hoymiles Smart Meter(three phase)
Hoymiles Smart Meter(three phase)
0% VAT in Germany only. For other countries, please check VAT Rate by Country
Only Compatible with Hoymiles HiBattery, HiFlow, and HiFlow Pro Series.
Features at a Glance
Features at a Glance
Plug & Play CT Connection
Zero Export Control
Space-Saving Design
WiFi & RS-485 Connectivity
DIN Rail Installation
High Accuracy Monitoring
Why Buy from Hoymiles.com?
Why Buy from Hoymiles.com?
Direct from Hoymiles
Official Warranty Standards
Free shipping in Germany (3-7 days)
30-day money back
Secure and easy payment
Lifetime customer service
Couldn't load pickup availability
More About Our Product
| Specification | Details |
|---|---|
| Installation Method | DIN rail installation |
| Meter Phases | Three-phase |
| Weight | 86 g |
| Dimensions | 19 × 94.5 × 68.5 mm |
| Input voltage range | 90 to 277 V ac L-N,156 to 480 V ac L-L |
| Frequency | 50/60 Hz |
| Current range | 0 to 120 A |
| Power consumption | <2W |
| Wireless Type | RS-485, Wi-Fi |
| Operating Temperature | -40°C to +70°C |
| Operating Humidity | ≤95% RH |
| Height of the Altitude | ≤2000 m |
| Protection Rating | IP20 |
Frequently Asked Questions
Where is the Smart Meter installed?
The Smart Meter is designed for DIN-35 rail mounting and fits standard electrical cabinets. Its plug-and-play CT connection enables quick and easy installation.
Is professional installation recommended?
Yes. Installation should be carried out by a qualified electrician according to local electrical regulations.
Which Hoymiles products is the Smart Meter compatible with?
Compatible with selected Hoymiles HiBattery, HiFlow and HiFlow Pro series products. Please refer to the product specifications or contact customer support for compatibility details.
Is this product compatible with third-party products?
As of now, this product is only compatible with Hoymiles products.
Can I monitor my energy usage in real time?
Yes. When connected to a compatible Hoymiles system, the Smart Meter provides real-time energy data in the S-Miles Home App.
